| LCD Plan Apo NIR Objective |
| Time:2025-5-14 11:41:11 Click:147 |
 |
| Description |
|
| ·Long working distance objective lens with an infinite conjugate focal distance of 95mm
·Chromatic aberration correction in the visible spectrum, suitable for coaxial observation and laser processing
·Suitable for laser processing at 532nm, 1030-1064nm
·Corresponding cover glass thicknesses are t=0, t=0.7, t=1.1, which can be achieved by replacing the appropriate protective lens holdert
|
Name |
Numerical
Aperture |
Working
Distance(mm) |
Focal
Length |
Resolution |
Depth of Field |
Actual Field of View(mm) |
Weight |
|
NA |
WD(mm) |
f(mm) |
R(um) |
±D.F(um) |
Φ24 eyepiece |
1"camera |
(9) |
|
LCD |
Plan |
Apo |
NIR |
20X(t0) |
0.4 |
20 |
10 |
0.7 |
1.7 |
1.2 |
0.48X0.64 |
260 |
|
LCD |
Plan |
Apo |
NIR |
20X(t0.7) |
0.4 |
20 |
10 |
0.7 |
1.7 |
1.2 |
0.48X0.64 |
259 |
|
LCD |
Plan |
Apo |
NIR |
20X(t1.1) |
0.4 |
20 |
10 |
0.7 |
1.7 |
1.2 |
0.48X0.64 |
258 |
|
LCD |
Plan |
Apo |
NIR |
50X(t0) |
0.45 |
15 |
4 |
0.6 |
1.4 |
0.48 |
0.19X0.26 |
300 |
|
LCD |
Plan |
Apo |
NIR |
50X(t0.7) |
0.45 |
15 |
4 |
0.6 |
1.4 |
0.48 |
0.19X0.26 |
299 |
|
LCD |
Plan |
Apo |
NIR |
50X(t1.1) |
0.45 |
15 |
4 |
0.6 |
1.4 |
0.48 |
0.19X0.26 |
298 |
The resolution and the objective lens depth of field are values calculated based on the reference wavelength λ=550nm.
| |
|
|
