Stereo Microscopes >> Zoom Stereo
Zoom6850 Series Zoom Stereo Microscopes
Description

Utilizing a new optical design incorporating a total reflection prism system the Zoom6850 delivers higher resolution, higher contrast and brighter images for industrial, biomedical and educational applications than traditional Greenough stereos.

With a built-in camera port and a 0.55x c-mount adapter, cameras can be directly mounted to the Zoom6850. Featuring an 8:1 zoom ratio (0.6x C 5.0x), a 115mm working distance and WF10x/23mm focusable eyepieces, the Zoom6850 is ideal for industrial inspection applications.

The Zoom6850 is a versatile, high performance, ergonomically designed zoom stereo microscope ruggedly built to withstand years of heavy usage.

Standard Specifications
0.6x C 5.0x zoom magnification range
Magnification range 6x-50x (with 10x eyepieces)
8:1 zoom ratio
30 viewing angle
115mm working distance
Interpupillary Distance Adjustment 55mm C 75mm
WF10x/23mm focusing eyepieces with roll down eyeguards
Airtight and anti-mold design

Specification





Zoom6850T(A)

Zoom6850T(B)

Viewing Tube

Trinocular viewing head, Inclined at 30

Diopter Adjustment
Eyepiece

Extra wide field eyepiece WF10X/23

WF15X/16

WF20X/12

WF30X/8

WF10X  Eyepiece with cross hair

Zoom Objective

0.6X-5X

Zoom Ratio

1:8.3

Working Distance

115mm

Interpupillary Distance

55-75mm

Auxiliary objective

0.5X  WD220mm

0.7X  WD125mm

2X   WD45mm

Stage Insert

Glass plate, Diameter 125mm



Glass plate, Diameter 100mm



Opal & black acrylic plate, Diameter 125mm



Opal & black acrylic plate, Diameter 100mm



Focusing Range

105mm

Illumination

Incident Illumination 100V-240V/LED

Transmitted Illumination 100V-240V/LED

LED ring illuminator

L-150A/LED40A Cold light power

Video Adapter

0.55x    C Mount

1x       C Mount

Polarization set



Dark field attachment



Note: Standard Outfit, Optional
