Specificaon

Modle

MB270A

MB270B

MB270T

Viewing Head

  Monocular Inclined at 45°,360°Rotatble

●





  Compensation Free Binocular Head, Inclined

  at 30°(55mm-75mm)



●



  Compensation Free Trinoculaar

  Head, Inclined

  at 30°(55mm-75mm)





●

Eyepiece

  WF10×/18mm

●

●

●

Objective

  Achromatic 4×、10×、40×(s)、100×(s)Oil

●

●

●

Nosepiece

  Backward Quadruple Nosepiece

●

●

●

Stage

  Double layer mechanical stage

●

●

●

  Stage Sixe:140mm×132mm

  Moving Range:70mm×30mm

Condenser

  N.A.1.25 Abbe condenser with iris diaphragm and

  filter

●

●

●

Fcusing

  Coaxial coarse & fine focusing adjustmenFine

  focusing scale value 0.002mm

●

●

●

Light Source

  Halogen bulb 6V20W or 6V15W, AC 220V/110V

●

●

●

  Adjustable light intensity

Optional Accessory

  Eyepiece：WF16×、WF20×、P16×

  Objective：20×、60(s)

  Semi-plan Objective:4×、10×、20×、40×(s)、60×(s)、100×(s)oil

  Plan Objective:4×、10×、20×、40×(s)、60×(s)、100×(s)oil

  Reflective Mirror, Demonstration(Teaching) HeadDark field and Phase contrast device

  1.3Mega、2.0Mega、3.0Mega、5.0Mega pixels CMOS Digital camera eyepiece

  Photography attchment and CCD Adapter 0.5×、0.57×、0.75×

  Compensation Free Binocular & Trinocular Head (48mm-75mm)

  LED illumination
