BW OPTICS

Items	Specification	MB260-N	MB260-D
Main Body		●	●
Eyepiece	WF10X/20mm	●●	●●
Eyepiece	WF16X	○○	○○
Infinity Objective	EPLAN 4X/0.10	●	●
	EPLAN 10X/0.25	●	●
	EPLAN 40X/0.65(S)	●	●
	EPLAN 100X/1.25(S，Oil)	●	●
	PLAN 4X/0.10	○	○
	PLAN 10X/0.25	○	○
	PLAN 20X/0.40(S)	○	○
	PLAN 40X/0.66(S)	○	○
	PLAN 60X/0.80(S)	○	○
	PLAN 100X/1.25(S，Oil)	○	○
	PLAN 100X/1.15(S，Water)	○	○
Observing Head	Seidentopf Binocular Head, Inclined 30°,Rotatable 360°, Interpupilary Distance: 50-75mm	●
	Seidentopf Trinocular Head, Inclined 30°,Rotatable 360°, Interpupilary Distance: 50-75mm	○
	3MP built in integrated digital head		●
	5MP built in integrated digital head		○
Nosepiece	Quadplex	●	●
Mechanical Stage	Size 125mmX120mm, Travel Range:76mmX30mm, Scale: 0.1mm	●	●
Mechanical Stage	Size 145mmX140mm, Travel Range:76mmX52mm, Scale: 0.1mm, Two Slide Holder	○	○
Abbe Condenser	N.A.1.25，With iris Diaphragm	●	●
Coaxial Coarse and Fine Focusing Knobs	Coarse Focusing Travel Range: 25mm Fine Focusing Travel Range: 2µm/division	●	●
Aspheric Illumination	3W LED Illumination，Voltage: 100V-240V	●	●
Dark Field Unit	Dark Field Ring (Dry, N.A.0.9)	○	○
Polarizing Unit	Analyzer, Polarizer	○	○
C-mount	1×C-mount（Available for Digital Photography）	○
C-mount	0.5×C-mount（Available for Digital Camera）	○	● (Built in)
Wire Winding Device		●	●

Note: ●In Table Is Standard outfits, ○ Is Optional Accessories.
