Digital Microscopes >> Digital microscopes
MD300 Digital Microscope
Description

Megapixels digital systems, high-resolution real-time micro-image.
With high-sensitivity feature, suitable for equipped wide range of accessories such as dark field , phase contrast, Epi-fluorescence and so on.
Excellent optical performance with infinity optical system.

Specification





MD300

Viewing Head

Built-in 3M pixel digital camera with Software ScopeImaage 9.0
Siedentopf binocular head,30inclined,interpupillary distance
48-75mm

Eyepiece

Wide Field Eyepiece WF10/ 18

Extra wide filed eyepiece EW10/ 20 with diopter
adjustment

Objective

Infinitive Semi-plan
chromatic objectives

4

10

40

100

Nosepiece

Quadruple Nosepiece

Stage

Double layers mechanical stage 140mm140mm/ 75mm50mm

Condenser

Sliding-in centerable condenser NA1.25

Focusing

Coaxial coarse and fine adjustment, moving range 20mm

Illumination

220V or 110V/ 6V/ 20W Halogen Lamp, Brightness Adjustable.

Phase
Contrast Kit



Dark Field
Attachment



Note: Standard Outfit, Optional
